| Varenummer | TV122WXM-NW0 |
| Mærke | BOE |
| Størrelse | 12.2 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 900:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | BOE |
| panel model | TV122WXM-NW0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.2 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 262.565×164.16 mm |
| omrids | 271.06×176.42×2.86 mm |
| overflade | |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193150% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | eDP (2 Lanes), 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
