| Varenummer | TX18D37VM0AQA |
| Mærke | KOE |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 380 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | KOE |
| panel model | TX18D37VM0AQA |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | IPS, Normally Black, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 178.76×115×15.62 mm |
| overflade | |
| lysstyrke | 380 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 45 (Max.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S4PWLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA104XG12 | Mitsubishi | 10.4 | 1024×768 |
| AA10SA6C-ADDD | Mitsubishi | 10.4 | 800×600 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
| LCBHBT161M | NAN YA | 5.7 | 320×240 |
| LM64C350 | SHARP | 10.4 | 640×480 |
| LTA057A347F | TOSHIBA | 5.7 | 320×240 |
| NL10276BC13-01C | NLT | 6.5 | 1024×768 |
| SX19V001-ZZA | KOE | 7.5 | 640×480 |
| UG-6028GDEAF01 | WiseChip | 1.45 | 160×128 |
