| Varenummer | AM-800480STMQW-W0 |
| Mærke | AMPIRE |
| Størrelse | 7.0 |
| Ansøgning | IA |
| Løsning | 800×480 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 400:1 |
| Farver | 65K |
| Baggrundsbelysning | WLED |
| Interface | CPU |
| panel mærke | AMPIRE |
| panel model | AM-800480STMQW-W0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 800(RGB)×480 , WVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 152.4×91.44 mm |
| omrids | 165×104.44×9.16 mm |
| overflade | |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 65K |
| responstid | 5/11 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/60/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S8PWLEDEmbedded (LED Driver) |
| signal interface | 8/9/16/18-bit 6800/8080 parallel, 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AM-800480-050D | Other | 5.0 | 800×480 |
| AM-800480LATMQW-TN0H | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-00H-F | AMPIRE | 5.0 | 800×480 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AM-800480R3TMQW-B2H | AMPIRE | 7.0 | 800×480 |
| AM-800480RCTMQW-00H | AMPIRE | 7.0 | 800×480 |
| AM-800480RSTMQW-TA1H | AMPIRE | 7.0 | 800×480 |
| AM-800480RWTMQW-TA4H | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-00 | AMPIRE | 7.0 | 800×480 |
| AM-800480STMQW-W0 | AMPIRE | 7.0 | 800×480 |
| AC156GA01 | Mitsubishi | 15.6 | 1366×768 |
| B084SN02 V0 | AUO | 8.4 | 800×600 |
| EL320.240.36 ET | Lumineq | 5.7 | 320×240 |
| KCB6448BSTT-X1 | Kyocera | 10.4 | 640×480 |
| LQ104S1LG32 | SHARP | 10.4 | 800×600 |
| LQ156M3LW01 | SHARP | 15.6 | 1920×1080 |
| PD050SX2 | E Ink | 5.0 | 800×600 |
| PM070WX9 | E Ink | 7.0 | 800×480 |
| TX18D30VM2FAA | KOE | 7.0 | 800×480 |
| TX26D12VM0AAA | KOE | 10.4 | 800×600 |
