| Varenummer | V236BJ1-P02 |
| Mærke | Innolux |
| Størrelse | 23.6 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | CELL |
| Lysstyrke | 0 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | No B/L |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | V236BJ1-P02 |
| paneltype | a-Si TFT-LCD , CELL |
| panelstørrelse | 23.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 521.471×293.184 mm |
| omrids | 535.06×306.34 mm |
| overflade | Antiglare (Haze 1%), Hard coating (3H) |
| glas dybde | 0.50+0.50 mm |
| transmissivitet | 5.4% (Typ.)(with Polarizer) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
