| Varenummer | V236BJ1-LE1 |
| Mærke | Innolux |
| Størrelse | 23.6 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 3000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | V236BJ1-LE1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 23.6 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | MVA, Normally Black, Transmissive |
| aktivt område | 521.471×293.184 mm |
| omrids | 544.8×320.5×11.9 mm |
| overflade | Antiglare (Haze 1%), Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 3000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193172% |
| responstid | 8.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
