| Varenummer | V580HJ1-LD6 |
| Mærke | Innolux |
| Størrelse | 58 |
| Ansøgning | LCTV |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 4000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | INNOLUX |
| panel model | V580HJ1-LD6 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 58 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 1270.08×721.44 mm |
| omrids | 1290.3×744.7×63.6 mm |
| overflade | Antiglare (Haze 1%) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 4000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 9.5 (Typ.)(G to G) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| LC320DXJ-SFK1 | LG Display | 31.5 | 1366×768 |
| LC320EUN-SEM2 | LG Display | 31.5 | 1920×1080 |
| LC420EUN-SFF3 | LG Display | 42 | 1920×1080 |
| LTA400HT-L07 | Samsung | 40 | 1920×1080 |
| LTA520HB13 | Samsung | 52 | 1920×1080 |
| T260XW05 V0 | AUO | 26.0 | 1366×768 |
| T320HVN01.0 | AUO | 31.5 | 1920×1080 |
| T460HVN08.2 CELL | AUO | 46 | 1920×1080 |
| V150V1-T02 | Innolux | 15.0 | 640×480 |
| V580DK1-LS1 | Innolux | 58 | 3840×2160 |
