| Varenummer | V150V1-T02 |
| Mærke | Innolux |
| Størrelse | 15.0 |
| Ansøgning | LCTV |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | CMO |
| panel model | V150V1-T02 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.0 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | Super MVA, Normally Black, Transmissive |
| aktivt område | 305.28×228.96 mm |
| omrids | 331.2×256 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H), Reflection 2.0% (Max.) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193172% |
| responstid | 15/10 (Typ.)(Tr/Td) |
| synsvinkel | 88/88/88/88 (Typ.)(CR≥20)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 pcsCCFLWithout Driver |
| signal interface | TTL (1 ch, 8-bit), 50 pins |
| indgangsspænding | 5.0V (Typ.)(VCC) |
| Ansøgning | LCTV |
