| Varenummer | WEO012864KS |
| Mærke | Winstar |
| Størrelse | 2.7 |
| Ansøgning | Handheld & PDA Instr |
| Løsning | 128×64 |
| Sammensætning | PM-OLED , OLED |
| Lysstyrke | |
| CR | |
| Farver | Mono(Blue) |
| Baggrundsbelysning | self |
| Interface | 8-bit |
| panel mærke | Winstar |
| panelstørrelse | 2.7" |
| løsning | 128×64, 52PPI |
| udstillingsområde | 61.41(W)×30.69(H) mm |
| konturstørrelse | 73(W)×41.86(H) ×2.15(D) mm |
| synsvinkel | - |
| bedste udsigt på | Symmetry |
| vise farver | Mono(Blue) |
| frekvens | - |
| driver ic | COG Built-in SSD1309ZC |
| panelvægt | - |
| signal interface | 8-bit 6800/8080 parallel, 4-wire SPI, I²C , 31 pins FPC |
| indgangsspænding | 3.0V (Typ.) |
| panel model | WEO012864KS |
| paneltype | PM-OLED , OLED |
| pixel format | Rectangle |
| bezel åbning | 63.41(W)×32.69(H) mm |
| overflade | - |
| visningstilstand | - |
| responstid | - |
| lampe type | self |
| berøringsskærm | Without |
| Ansøgning | Handheld & PDA Instruments & Meters |
