| Varenummer | TM027CDH19 |
| Mærke | Tianma |
| Størrelse | 2.7 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | 400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | TIANMA |
| panel model | TM027CDH19 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 2.7 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 54×40.5 mm |
| overflade | |
| lysstyrke | |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193145% |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 60/60/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | WLED |
| signal interface | Serial RGB (8-bit) + SPI, CCIR601/656, 39 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | DSC |
