| Varenummer | A035QN02 VE |
| Mærke | AUO |
| Størrelse | 3.5 |
| Ansøgning | DSC |
| Løsning | 320×240 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | Serial RGB |
| panel mærke | AUO |
| panel model | A035QN02 VE |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 3.5 inch |
| løsning | 320(RGB)×240 , QVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 70.08×52.56 mm |
| omrids | 76.9×63.9×3.12 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193160% |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6S1PWLEDWithout Driver |
| signal interface | Serial RGB (8-bit) + SPI, 50 pins |
| indgangsspænding | 3.3/3.3V (Typ.)(VCI/VDDIO) |
| Ansøgning | DSC |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| A035QN02 VE | AUO | 3.5 | 320×240 |
| A035QN05 V0 | AUO | 3.5 | 320×240 |
| A035QN05 V1 | AUO | 3.5 | 320×240 |
| AMS347FF02 | Samsung | 3.5 | 360×640 |
| C035QVN01.0 | AUO | 3.5 | 240×320 |
| DLC0350CZG-T | Other | 3.5 | 320×240 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| T-51963GD035J-MLW-AJN | Kyocera | 3.5 | 240×320 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
| A015AN05 V0 | AUO | 1.5 | 280×220 |
| A027DN03 V5 | AUO | 2.7 | 320×240 |
| A027DTN01.2 | AUO | 2.7 | 320×240 |
| A027DTN01.3 | AUO | 2.7 | 320×240 |
| A030DN04 V0 | AUO | 3.0 | 320×240 |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| CT025TN01 | Innolux | 2.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| PT035TN23 V.3 | Innolux | 3.5 | 320×240 |
| TM035KDH04 | Tianma | 3.5 | 320×240 |
