| Varenummer | A081VW01 V0 |
| Mærke | AUO |
| Størrelse | 8.1 |
| Ansøgning | GM |
| Løsning | 800×300 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 300:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | AUO |
| panel model | A081VW01 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.1 inch |
| løsning | 800(RGB)×300 , HSVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 192×72 mm |
| omrids | 204.6×86.2 mm |
| overflade | Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 300:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 10/20 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 4S1PWLEDWithout Driver |
| signal interface | TTL (1 ch, 6/8-bit) + SPI, 60 pins |
| indgangsspænding | 3.3/11/3.3/15/-7V (Typ.)(VDD/AVDD/GVCC/VGH/VGL) |
| Ansøgning | GM |
