| Varenummer | AMS495QA01 |
| Mærke | Samsung |
| Størrelse | 5.0 |
| Ansøgning | GM |
| Løsning | 960×544 |
| Sammensætning | OLED |
| Lysstyrke | 140 |
| CR | 6500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | self |
| Interface | MIPI |
| panel mærke | SAMSUNG |
| panel model | AMS495QA01 |
| paneltype | AM-OLED , OLED |
| panelstørrelse | 5.0 inch |
| løsning | 960(RGB)×544 , qHD |
| aktivt område | 109.44×62.02 mm |
| omrids | 116.54×73.92 mm |
| overflade | |
| lysstyrke | 140 cd/m² (Typ.) |
| kontrastforhold | 6500 : 1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE1931100% |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥200)(L/R/U/D) |
| frekvens | 60Hz |
| driver ic | Built-in D53E6EA8933 |
| signal interface | MIPI (2 data lanes), 40 pins |
| indgangsspænding | 1.8/3.0/V (Typ.)(VDD/VCI/ELVDD/ELVSS) |
| Ansøgning | GM |
