| Varenummer | LT121AC53000 |
| Mærke | TOSHIBA |
| Størrelse | 12.1 |
| Ansøgning | GM |
| Løsning | 466×350 |
| Sammensætning | LCM |
| Lysstyrke | 400 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Toshiba Mobile Display |
| panel model | LT121AC53000 |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 466×350(RGB) |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 245.7×184.275 mm |
| omrids | 310×225 mm |
| overflade | Hard coating |
| lysstyrke | 400 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8/17 (Typ.)(Tr/Td) |
| synsvinkel | 60/60/45/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | GM |
