| Varenummer | A260J2-001 |
| Mærke | Innolux |
| Størrelse | 25.5 |
| Ansøgning | DMPC |
| Løsning | 1920×1200 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | RSDS |
| panel mærke | CHIMEI INNOLUX |
| panel model | A260J2-001 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 25.5 inch |
| løsning | 1920(RGB)×1200 , WUXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 550.08×343.8 mm |
| omrids | 582×375.6 mm |
| overflade | Antiglare (Haze 25%), Hard coating (3H) |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 1/4 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 16 pcsCCFLWithout Driver |
| signal interface | RSDS (2 Channel), 90 pins |
| Ansøgning | DMPC |
| CLAA150XP01Q | CPT | 15.0 | 1024×768 |
| HT236F01-100 | BOE | 23.6 | 1920×1080 |
| LM150X08-A4KD | LG Display | 15.0 | 1024×768 |
| LM215WF3-SLD1 | LG Display | 21.5 | 1920×1080 |
| LM240WU4-SLB1 | LG Display | 24.0 | 1920×1200 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM300W01-STA1 | LG Display | 30.0 | 2560×1600 |
| LTM270DL02 | Samsung | 27.0 | 2560×1440 |
| M220EW01 V2 | AUO | 22.0 | 1680×1050 |
| M240UW01 V2 | AUO | 24.0 | 1920×1200 |
