| Varenummer | AA084VG01 |
| Mærke | Mitsubishi |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | Mitsubishi |
| panel model | AA084VG01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 170.88×128.16 mm |
| omrids | 199.5×149 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193140% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 stringsWLEDWithout Driver |
| signal interface | CMOS (1 ch, 6-bit), 31 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA084VC05 | Mitsubishi | 8.4 | 640×480 |
| AA084VG01 | Mitsubishi | 8.4 | 640×480 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| AA084XB11 | Mitsubishi | 8.4 | 1024×768 |
| AA090AA01 | Mitsubishi | 9.0 | 960×540 |
| DMF-50773NB-FW | Kyocera | 5.4 | 240×128 |
| EL320.240.36 AGL | Lumineq | 5.7 | 320×240 |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G158ETN01.0 | AUO | 15.8 | |
| G220SW01 V0 | AUO | 22.0 | 1680×1050 |
| KCL6448HSTT-X12 | Kyocera | 9.4 | 640×480 |
| LM32004 | SHARP | 5.7 | 320×240 |
| LQ150X1LW96 | SHARP | 15.0 | 1024×768 |
| OEL9M0064-B-E | Other | 2.0 | 128×32 |
