| Varenummer | AA084XA03 |
| Mærke | Mitsubishi |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 1024×768 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 400:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA084XA03 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 1024(RGB)×768 , XGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 171.264×128.448 mm |
| omrids | 205×152.4 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| responstid | 6/19 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA084SB01 | Mitsubishi | 8.4 | 800×600 |
| AA084SC01 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084VB01 | Mitsubishi | 8.4 | 640×480 |
| AA084VC03 | Mitsubishi | 8.4 | 640×480 |
| AA084VC05 | Mitsubishi | 8.4 | 640×480 |
| AA084VD02 | Mitsubishi | 8.4 | 640×480 |
| AA084VG01 | Mitsubishi | 8.4 | 640×480 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| G150XG01 V0 | AUO | 15.0 | 1024×768 |
| G220SW02 V0 | AUO | 22.0 | 1680×1050 |
| LQ057V3DG01 | SHARP | 5.7 | 640×480 |
| LQ104V1DG5B | SHARP | 10.4 | 640×480 |
| LQ281L1LW12 | SHARP | 28.1 | 2048×2048 |
| M150MNN1 R1 | IVO | 15.0 | 1024×768 |
| NL12876AC18-03 | NLT | 10.6 | 1280×768 |
| NL6448BC33-49 | NLT | 10.4 | 640×480 |
| SX19V007 | KOE | 7.5 | 640×480 |
| UG-2864HSWEG01 | WiseChip | 0.96 | 128×64 |
