| Varenummer | AA106TA01DDE11 |
| Mærke | Mitsubishi |
| Størrelse | 10.6 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1280×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | |
| mærke | Mitsubishi |
| model | AA106TA01DDE11 |
| diagonal størrelse | 10.6 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×768 [WXGA] 140PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 231.36(H)×138.816(V) mm |
| omrids dim. | 250(H)×175(V) ×15.5(D) mm |
| bezel område | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 800 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 12/12 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | SWV, Normally Black, Transmissive |
| støtte farve | 262K/16.7M 50% NTSC |
| lyskilde | WLED , 100K hours , With LED Driver |
| vægt | 670g (Typ.) |
| designet til | Industrial Outdoor High Brightness |
| billedhastighed | 60Hz |
| berøringspanel | PCAP |
| Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| AA106TA01 | Mitsubishi | 10.6 | 1280×768 |
| LQ106K1LA01C | SHARP | 10.6 | 1280×768 |
| LQ106K1LA02 | SHARP | 10.6 | 1280×768 |
| LQ106K1LA05 | SHARP | 10.6 | 1280×768 |
| LTD106EWNN | TOSHIBA | 10.6 | 1280×768 |
| LTL106AL01-001 | Samsung | 10.6 | 1366×768 |
| LTL106HL01-001 | Samsung | 10.6 | 1920×1080 |
| LTN106W1-L01 | Samsung | 10.6 | 1280×768 |
| LTN106W2-L01 | Samsung | 10.6 | 1280×768 |
