| Varenummer | AA190EA01 |
| Mærke | Mitsubishi |
| Størrelse | 19.0 |
| Ansøgning | IA |
| Løsning | 1280×1024 |
| Sammensætning | LCM |
| Lysstyrke | 1500 |
| CR | 800:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA190EA01 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1280(RGB)×1024 , SXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 376.32×301.056 mm |
| omrids | 404.2×330×15.4 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 1500 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC) |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4 strings × 2CNWLEDWithout Driver |
| signal interface | LVDS (2 ch, 6/8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | IA |
| AA190EA01 | Mitsubishi | 19.0 | 1280×1024 |
| AA192AA01 | Mitsubishi | 19.2 | 1920×360 |
| HSD190MEN3-A00 | HannStar | 19.0 | 1280×1024 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LQ190E1LW42 | SHARP | 19.0 | 1280×1024 |
| LTB190E2-L01 | Samsung | 19.0 | 1280×1024 |
| LTM190EX-L31 | Samsung | 19.0 | 1280×1024 |
| M190EN03 V2 | AUO | 19.0 | 1280×1024 |
| MT190EN02 V.Y | Innolux | 19.0 | 1280×1024 |
| TX48D80VM1CAA | KOE | 19.0 | 1024×768 |
| AA070ME01 | Mitsubishi | 7.0 | 800×480 |
| AA121SL09 | Mitsubishi | 12.1 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G150XG03 V5 | AUO | 15.0 | 1024×768 |
| LB064V02-A1 | LG Display | 6.4 | 640×480 |
| LQ104S1LG61 | SHARP | 10.4 | 800×600 |
| LQ104S1LG81 | SHARP | 10.4 | 800×600 |
| LQ9D023 | SHARP | 8.4 | 640×480 |
| M101GWN9 R0 | IVO | 10.1 | 1024×600 |
| NL4823BC37-05 | NLT | 7.0 | 480×234 |
