| Varenummer | LM190WX1-TLL1 |
| Mærke | LG Display |
| Størrelse | 19.0 |
| Ansøgning | DMPC |
| Løsning | 1440×900 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LM190WX1-TLL1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 19.0 inch |
| løsning | 1440(RGB)×900 , WXGA+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 408.24×255.15 mm |
| omrids | 428×278×15 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC) |
| responstid | 1.3/3.7 (Typ.)(Tr/Td) |
| synsvinkel | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 30 pins |
| indgangsspænding | 5.0V (Typ.) |
| Ansøgning | DMPC |
| HSD190ME12-A02 | HannStar | 19.0 | 1280×1024 |
| HSD190MEN6-A01 | HannStar | 19.0 | 1280×1024 |
| HT190WG1-100 | BOE | 19.0 | 1440×900 |
| LM190WX1-TLA1 | LG Display | 19.0 | 1440×900 |
| LM190WX1-TLC1 | LG Display | 19.0 | 1440×900 |
| LM190WX1-TLL1 | LG Display | 19.0 | 1440×900 |
| LM190WX2-TLK1 | LG Display | 19.0 | 1440×900 |
| LTM190EX-L01 | Samsung | 19.0 | 1280×1024 |
| M190EN04 V1 | AUO | 19.0 | 1280×1024 |
| MT190AW01 V.7 | Innolux | 19.0 | 1440×900 |
| HSD190MGW1-B00 | HannStar | 19.0 | 1440×900 |
| LM195WD1-TLA1 | LG Display | 19.5 | 1600×900 |
| LM195WD1-TLC1 | LG Display | 19.5 | 1600×900 |
| LM201WE3-TLF8 | LG Display | 20.1 | 1680×1050 |
| LM230WF1-TLA5 | LG Display | 23.0 | 1920×1080 |
| LM238WF2-SSF1 | LG Display | 23.8 | 1920×1080 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| M236HJJ-L30 | Innolux | 23.6 | 1920×1080 |
| M270HGE-L30 | Innolux | 27.0 | 1920×1080 |
| TM190MDS01 | Tianma | 19.0 | 1440×900 |
