| Varenummer | AC121SA04 |
| Mærke | Mitsubishi |
| Størrelse | 12.1 |
| Ansøgning | Industrial |
| Løsning | 800×600 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | Mitsubishi |
| model | AC121SA04 |
| diagonal størrelse | 12.1 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×600 [SVGA] 82PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 246(H)×184.5(V) mm |
| omrids dim. | 260.5(H)×203(V) ×10(D) mm |
| bezel område | 249.0(H)×187.5(V) mm |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) (TM) |
| visningsretning | 6 o'clock |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/60/80 (Typ.)(CR≥10) |
| driftstilstand | TN, Normally White, Transmissive |
| støtte farve | 262K/16.7M 72% NTSC |
| lyskilde | WLED , 70K hours , With LED Driver |
| vægt | 580g (Typ.) |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
