| Varenummer | AA121TD01-DE3 |
| Mærke | Mitsubishi |
| Størrelse | 12.1 |
| Ansøgning | IA |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 640 |
| CR | 700:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | Mitsubishi |
| panel model | AA121TD01-DE3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.1 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 261.12×163.2 mm |
| omrids | 303×205.1×16.3 mm |
| overflade | Clear, Hard coating (5H) |
| lysstyrke | 640 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 80/80/80/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6/8-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AA121TD01 | Mitsubishi | 12.1 | 1280×800 |
| AA121TD01-DE3 | Mitsubishi | 12.1 | 1280×800 |
| AA121TD02 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH01-DE1 | Mitsubishi | 12.1 | 1280×800 |
| AA121TH11-DE1 | Mitsubishi | 12.1 | 1280×800 |
| LT121DEE3P00 | TOSHIBA | 12.1 | 1024×768 |
| LT121SL-105 | Samsung | 12.1 | 800×600 |
| LTD121EA3KZ | TOSHIBA | 12.1 | 1024×768 |
| LTD121ECBP | TOSHIBA | 12.1 | 1024×768 |
| NL10276BC24-21 | NLT | 12.1 | 1024×768 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| LM-CA53-22NTK | SANYO | 9.4 | 640×480 |
| LM-CC53-22NDK | SANYO | 10.4 | 640×480 |
| LQ057Q3DC12 | SHARP | 5.7 | 320×240 |
| LQ070Y3DG3A | SHARP | 7.0 | 800×480 |
| LTM084P363 | TOSHIBA | 8.4 | 800×600 |
| OEL9M0072-B-E | Other | 1.54 | 128×64 |
| RGS11096096FR006 | RiTdisplay | 1.1 | 96×96 |
| SP14Q002-A1 | KOE | 5.7 | 320×240 |
| SX25S004 | KOE | 10.0 | 800×600 |
