| Varenummer | AM-1024768V1TZQW-A0H |
| Mærke | AMPIRE |
| Størrelse | 8.4 |
| Ansøgning | Industrial |
| Løsning | 1024×768 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | AMPIRE |
| model | AM-1024768V1TZQW-A0H |
| diagonal størrelse | 8.4 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1024(RGB)×768 [XGA] 152PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 170.8(H)×128.1(V) mm |
| omrids dim. | 203(H)×145.5(V) ×8(D) mm |
| bezel område | 174.15(H)×131.2(V) mm |
| behandling | - |
| luminans | 1000 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | IPS, Normally Black, Transmissive |
| støtte farve | 16.7M |
| lyskilde | WLED [6S6P] , 50K hours , With LED Driver |
| vægt | - |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 8-bit) , 20 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 85 °C |
