| Varenummer | AM-1280800P4TZQW-T01H |
| Mærke | AMPIRE |
| Størrelse | 7.0 |
| Ansøgning | Industrial Outdoor H |
| Løsning | 1280×800 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | |
| mærke | AMPIRE |
| model | AM-1280800P4TZQW-T01H |
| diagonal størrelse | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×800 [WXGA] 217PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 149.76(H)×93.6(V) mm |
| omrids dim. | 162.3(H)×107.9(V) ×11.76(D) mm |
| bezel område | 152.76(H)×96.6(V) mm |
| behandling | - |
| luminans | 1275 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 35 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | SFT, Normally Black, Transmissive |
| støtte farve | 16.7M 50% NTSC |
| lyskilde | WLED [5S4P] , 50K hours , With LED Driver |
| vægt | - |
| designet til | Industrial Outdoor High Brightness |
| billedhastighed | 60Hz |
| berøringspanel | PCAP |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
