| Varenummer | A070FW03 V7 |
| Mærke | AUO |
| Størrelse | 7.0 |
| Ansøgning | CNS |
| Løsning | 480×234 |
| Sammensætning | LCM |
| Lysstyrke | 280 |
| CR | 400:1 |
| Farver | |
| Baggrundsbelysning | WLED |
| Interface | Analog |
| panel mærke | AUO |
| panel model | A070FW03 V7 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.0 inch |
| løsning | 480(RGB)×234 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 154.08×86.58 mm |
| omrids | 164.9×100 mm |
| overflade | Antiglare (Haze 25%) |
| lysstyrke | 280 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | |
| responstid | 12/18 (Typ.)(Tr/Td) |
| synsvinkel | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S7PWLEDWithout Driver |
| signal interface | TFT Specific Analog RGB, 26 pins |
| indgangsspænding | 5/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| Ansøgning | CNS |
| A070FW01 | AUO | 7.0 | 480×234 |
| A070FW03 V1 | AUO | 7.0 | 480×234 |
| A070FW03 V3 | AUO | 7.0 | 480×234 |
| A070FW03 V4 | AUO | 7.0 | 480×234 |
| A070FW03 V6 | AUO | 7.0 | 480×234 |
| A070FW03 V7 | AUO | 7.0 | 480×234 |
| A070FW03 V8 | AUO | 7.0 | 480×234 |
| A070FW03 VB | AUO | 7.0 | 480×234 |
| A070FW03 VD | AUO | 7.0 | 480×234 |
| A070FW05 V1 | AUO | 7.0 | 480×234 |
| CLAA069LA0NCW | CPT | 7.0 | 800×480 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| GCX123AKQ-E | JDI | 3.5 | 240×320 |
| LB043WQ4-TD01 | LG Display | 4.3 | 480×272 |
| LQ065Y5DG03 | SHARP | 6.5 | 800×480 |
| P070BAG-CM1 | Innolux | 7.0 | 1024×600 |
| PA080XS2 | E Ink | 7.9 | 480×468 |
| PM065WX3 | E Ink | 6.5 | 800×480 |
| TFD65W30 | TOSHIBA | 6.5 | 400×234 |
| TM062RDS01 | Tianma | 6.2 | 800×480 |
