| Varenummer | AM-640480G4TNQW-TA0H |
| Mærke | AMPIRE |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 640×480 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| fabrikant | AMPIRE |
| modelnavn | AM-640480G4TNQW-TA0H |
| skærmstørrelse | 5.7 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 640(RGB)×480 (VGA) 141PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 115.2 × 86.4 (H×V) |
| omrids (mm) | 127 × 98.43 × 9.1 (H×V×D) |
| rammeareal (mm) | 118.0 × 89.2 (H×V) |
| behandling | - |
| luminans | 450 cd/m² (Typ.) |
| kontrastforhold | 250 : 1 (Typ.) (TM) |
| synsvinkel | 70/70/50/50 (Typ.)(CR≥10) |
| respons | 50 (Typ.)(Tr+Td) ms |
| god udsigt kl | 12 o'clock |
| arbejdstilstand | TN, Normally White, Transmissive |
| farvedybde | 262K 50% NTSC |
| baggrundsbelysning | WLED , 20K hours , With LED Driver |
| masse | - |
| anvendes til | Industrial |
| opdateringshastighed | 60Hz |
| berøringsskærm | 4-wire Resistive Touch |
| signaltype | LVDS (1 ch, 6-bit) , Connector 20 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
