| Varenummer | AM-640480G4TNQW-A0H |
| Mærke | AMPIRE |
| Størrelse | 5.7 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | AMPIRE |
| panel model | AM-640480G4TNQW-A0H |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.7 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 115.2×86.4 mm |
| omrids | 127×98.43×7.5 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 50 (Typ.)(Tr+Td) |
| synsvinkel | 70/70/50/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
| AM-640480G2TNQW-00H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-31H-F | AMPIRE | 5.7 | 640×480 |
| AM-640480G2TNQW-T01H-A | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-A0H | AMPIRE | 5.7 | 640×480 |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| AM-640480GJTNQW-TA0H | AMPIRE | 5.7 | 640×480 |
| CLAA057VA02CW | CPT | 5.7 | 640×480 |
| KCG057QV1DB-G56 | Kyocera | 5.7 | 320×240 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| COM70T7M17ZLC | ORTUSTECH | 7.0 | 800×480 |
| LB104V03-TD01 | LG Display | 10.4 | 640×480 |
| LM32P101 | SHARP | 4.7 | 320×240 |
| LTA121B860F | TOSHIBA | 12.1 | 800×600 |
| LTD104C11Z | TOSHIBA | 10.4 | 640×480 |
| LTD121C31S | TOSHIBA | 12.1 | 800×600 |
| NL6448AC33-29 | NLT | 10.4 | 640×480 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TX26D05VM1CAA | KOE | 10.4 | 640×480 |
