| Varenummer | AM-640480VTZQW-A0H |
| Mærke | AMPIRE |
| Størrelse | 5.7 |
| Ansøgning | Industrial |
| Løsning | 640×480 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1200:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | |
| mærke | AMPIRE |
| model | AM-640480VTZQW-A0H |
| diagonal størrelse | 5.7 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 640(RGB)×480 [VGA] 141PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 115.2(H)×86.4(V) mm |
| omrids dim. | 127(H)×98.43(V) ×7.8(D) mm |
| bezel område | 118.0(H)×89.2(V) mm |
| behandling | - |
| luminans | 500 cd/m² (Typ.) |
| kontrastforhold | 1200:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | IPS, Normally Black, Transmissive |
| støtte farve | 262K 63% NTSC |
| lyskilde | WLED [4S7P] , 50K hours , W/O Driver |
| vægt | - |
| designet til | Industrial |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
