| Varenummer | AM-800600M3TNQW-01H-G |
| Mærke | AMPIRE |
| Størrelse | 8.4 |
| Ansøgning | Industrial |
| Løsning | 800×600 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | 12S4P |
| Interface | LVDS |
| fabrikant | AMPIRE |
| modelnavn | AM-800600M3TNQW-01H-G |
| skærmstørrelse | 8.4 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 800(RGB)×600 (SVGA) 119PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 170.4 × 127.8 (H×V) |
| omrids (mm) | 203 × 145.5 × 8.3 (H×V×D) |
| rammeareal (mm) | 174.15 × 131.2 (H×V) |
| behandling | - |
| luminans | 450 cd/m² (Typ.) |
| kontrastforhold | 600 : 1 (Typ.) (TM) |
| synsvinkel | 75/75/60/70 (Typ.)(CR≥10) |
| respons | 8 (Typ.)(Tr+Td) ms |
| god udsigt kl | - |
| arbejdstilstand | TN, Normally White, Transmissive |
| farvedybde | 262K |
| baggrundsbelysning | 12S4P WLED , 50K hours , With LED Driver |
| masse | 280g |
| anvendes til | Industrial |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (1 ch, 6-bit) , Connector 20 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
