| Varenummer | LTM08C343S |
| Mærke | TOSHIBA |
| Størrelse | 8.4 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 70 |
| CR | 250:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | TOSHIBA |
| panel model | LTM08C343S |
| paneltype | LTPS TFT-LCD , LCM |
| panelstørrelse | 8.4 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 170.4×127.8 mm |
| omrids | 201.4×140.3 mm |
| overflade | |
| lysstyrke | 70 cd/m² (Typ.) |
| kontrastforhold | 250:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 50/50 (Max.)(Tr/Td) |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.)(VDD) |
| Ansøgning | IA |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| KCB084SV1AC-G40 | Kyocera | 8.4 | 800×600 |
| LTM084P363 | TOSHIBA | 8.4 | 800×600 |
| LTM08C343S | TOSHIBA | 8.4 | 800×600 |
| LTM08C351 | TOSHIBA | 8.4 | 800×600 |
| LTM08C351L | TOSHIBA | 8.4 | 800×600 |
| LTM08C351S | TOSHIBA | 8.4 | 800×600 |
| LTM08C355S | TOSHIBA | 8.4 | 800×600 |
| LTM08C356F | TOSHIBA | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| G065VN01 V0 | AUO | 6.5 | 640×480 |
| G150XTN03.1 | AUO | 15.0 | 1024×768 |
| KG057QV1CA-G02 | Kyocera | 5.7 | 320×240 |
| KG057QV1CF-G050 | Kyocera | 5.7 | 320×240 |
| LMBHAT014G16CKS | NAN YA | 5.4 | 240×128 |
| LT084AC27900 | TOSHIBA | 8.4 | 800×600 |
| TFD50W72MS | TOSHIBA | 5.0 | |
| TM150TDS50 | Tianma | 15.0 | 1024×768 |
| TX26D02VM1CAA | KOE | 10.4 | 640×480 |
