| Varenummer | ASI545FB01-0 |
| Mærke | Samsung |
| Størrelse | 55 |
| Ansøgning | DID |
| Løsning | 1920×1080 |
| Sammensætning | OLED |
| Lysstyrke | 500 |
| CR | |
| Farver | 1.07B |
| Baggrundsbelysning | self |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | ASI545FB01-0 |
| paneltype | TOLED , OLED |
| panelstørrelse | 55 inch |
| løsning | 1920×1080(RGB) , FHD |
| aktivt område | 1209.6×680.4 mm |
| omrids | 1219.4×697 mm, Videowall Seam 9.8 mm |
| overflade | Hard coating (2H), Antireflection |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | |
| vise farver | 1.07B (10-bit), CIE1931100% |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| signal interface | LVDS (2 ch, 10-bit), 51 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DID |
