| Varenummer | LD470DXS-SCA1 |
| Mærke | LG Display |
| Størrelse | 47 |
| Ansøgning | DID |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 1400:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | LG Display |
| panel model | LD470DXS-SCA1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 47 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | S-IPS, Normally Black, Transmissive |
| aktivt område | 1039.87×584.64 mm |
| omrids | 1046.8×591.6×50.5 mm, Videowall Seam 6.9 mm |
| overflade | Hard coating (3H), Reflection 2.0% (Max.) |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 1400:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193172% |
| responstid | 12 (Typ.)(G to G) |
| synsvinkel | 89/89/89/89 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | DID |
