| Varenummer | AT056TN52 V.2 |
| Mærke | Innolux |
| Størrelse | 5.6 |
| Ansøgning | IA |
| Løsning | 640×480 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | TTL |
| panel mærke | INNOLUX |
| panel model | AT056TN52 V.2 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 5.6 inch |
| løsning | 640(RGB)×480 , VGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 112.896×84.672 mm |
| omrids | 126.5×100 mm |
| overflade | Antiglare |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 10/15 (Typ.)(Tr/Td) |
| synsvinkel | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 3S6PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit), 50 pins |
| indgangsspænding | 3.3/5.0/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| rohs: | |
| Ansøgning | IA |
| AT056TN03 | Innolux | 5.6 | 320×234 |
| AT056TN04 V.6 | Innolux | 5.6 | 320×234 |
| AT056TN52 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.2 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.3 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.4 | Innolux | 5.6 | 640×480 |
| AT056TN52 V.5 | Innolux | 5.6 | 640×480 |
| AT056TN53 V.1 | Innolux | 5.6 | 640×480 |
| CLAA150XP06CW | CPT | 15.0 | 1024×768 |
| DMF-51043NFU-FW-1 | Kyocera | 9.4 | 640×480 |
| HV121X02-100 | HYDIS | 12.1 | 1024×768 |
| LM12S472 | SHARP | 12.1 | 800×600 |
| LQ070Y3LG4A | SHARP | 7.0 | 800×480 |
| LQ130V3FZ20G | SHARP | 13.0 | 640×480 |
| LQ64D34 | SHARP | 6.4 | 640×480 |
| NL10276BC16-06D | NLT | 8.4 | 1024×768 |
| SX25S004 | KOE | 10.0 | 800×600 |
| TX18D30VM2FAA | KOE | 7.0 | 800×480 |
