| Varenummer | SX25S004 |
| Mærke | KOE |
| Størrelse | 10.0 |
| Ansøgning | IA |
| Løsning | 800×600 |
| Sammensætning | LCM |
| Lysstyrke | 100 |
| CR | 50:1 |
| Farver | Color |
| Baggrundsbelysning | CCFL |
| Interface | Parallel Data |
| panel mærke | HITACHI |
| panel model | SX25S004 |
| paneltype | CSTN-LCD , LCM |
| panelstørrelse | 10.0 inch |
| løsning | 800(RGB)×600 , SVGA |
| visningstilstand | STN, Normally Black, Transmissive |
| aktivt område | 202.8×152.1 mm |
| omrids | 236×168×6.3 mm |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 100 cd/m² (Typ.) |
| kontrastforhold | 50:1 (Typ.) |
| vise farver | Color |
| responstid | 170/130 (Typ.)(Tr/Td) |
| synsvinkel | 40 (Typ.)(CR≥2, Φ2-Φ1)(L/R/U/D) |
| frekvens | 120Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel Data (2ch, 8-bit), 40 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | IA |
