| Varenummer | AV080WSM-NW3 |
| Mærke | BOE |
| Størrelse | 8.0 |
| Ansøgning | CNS |
| Løsning | 1024×600 |
| Sammensætning | LCM |
| Lysstyrke | 600 |
| CR | 800:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | AV080WSM-NW3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 1024(RGB)×600 , WSVGA |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 176.64×99.36 mm |
| omrids | 192.8×116.9×7.1 mm |
| overflade | |
| lysstyrke | 600 cd/m² (Typ.) |
| kontrastforhold | 800:1 (Typ.) |
| vise farver | 16.7M (6-bit + Hi-FRC), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 3S10PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 40 pins |
| indgangsspænding | 3.3/11.5/24/-10V (Typ.)(VDD/AVDD/VGH/VGL) |
| Ansøgning | CNS |
