| Varenummer | CLAA080UA01 |
| Mærke | CPT |
| Størrelse | 8.0 |
| Ansøgning | UMPC |
| Løsning | 1600×768 |
| Sammensætning | LCM |
| Lysstyrke | 340 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | CPT |
| panel model | CLAA080UA01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 8.0 inch |
| løsning | 1600(RGB)×768 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 182.4×87.552 mm |
| omrids | 195.3×111.5×3.375 mm |
| overflade | Antiglare (Haze 42%), Hard coating (3H) |
| lysstyrke | 340 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193145% |
| responstid | 16 (Typ.)(Tr+Td) |
| synsvinkel | 35/35/10/30 (Min.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 8S4PWLEDWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 2.5V (Typ.) |
| Ansøgning | UMPC |
