| Varenummer | LQ065T9DZ03 |
| Mærke | SHARP |
| Størrelse | 6.5 |
| Ansøgning | CNS |
| Løsning | 400×240 |
| Sammensætning | LCM |
| Lysstyrke | 250 |
| CR | 260:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | TTL |
| panel mærke | SHARP |
| panel model | LQ065T9DZ03 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 6.5 inch |
| løsning | 400(RGB)×240 , WQVGA |
| visningstilstand | TN, Normally White, Transflective |
| aktivt område | 143.4×79.326 mm |
| omrids | 155×89.2 mm |
| overflade | Antiglare, Antireflection |
| lysstyrke | 250 cd/m² (Typ.) |
| kontrastforhold | 260:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| vise farver | 262K (6-bit) |
| responstid | 10/25 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/45/45 (Typ.)(CR≥15)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | Parallel RGB (1 ch, 6-bit), 31 pins |
| indgangsspænding | 5/10/-10V (Typ.)(VSH/VGH/VGL) |
| Ansøgning | CNS |
| LQ065T5AR05 | SHARP | 6.5 | 400×234 |
| LQ065T5BR08 | SHARP | 6.5 | 400×240 |
| LQ065T5DG05 | SHARP | 6.5 | 480×234 |
| LQ065T5GA01 | SHARP | 6.5 | 400×234 |
| LQ065T5GG63 | SHARP | 6.5 | 400×234 |
| LQ065T9BR54U | SHARP | 6.5 | 400×240 |
| LQ065T9DR51U | SHARP | 6.5 | 400×240 |
| LQ065T9DR52U | SHARP | 6.5 | 400×240 |
| LQ065T9DZ03 | SHARP | 6.5 | 400×240 |
| LQ065Y5DZ01 | SHARP | 6.5 | 800×480 |
| C065GW03 V3 | AUO | 6.5 | 400×240 |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LA050WQ1-TD01 | LG Display | 5.0 | 480×272 |
| LQ070Y5DG11 | SHARP | 7.0 | 800×480 |
| LQ080Y5DR01 | SHARP | 8.0 | 800×480 |
| LQ088H9DR01U | SHARP | 8.8 | 640×240 |
| LTA070B052F | TOSHIBA | 7.0 | 800×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
| TFD65W46 | TOSHIBA | 6.5 | 480×234 |
