| Varenummer | AV123Z7M-N11 |
| Mærke | BOE |
| Størrelse | 12.3 |
| Ansøgning | CNS |
| Løsning | 1920×720 |
| Sammensætning | LCM |
| Lysstyrke | 800 |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | BOE |
| panel model | AV123Z7M-N11 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 12.3 inch |
| løsning | 1920(RGB)×720 |
| visningstilstand | ADS, Normally Black, Transmissive |
| aktivt område | 292.032×109.512 mm |
| omrids | 307.9×130.27 mm |
| overflade | |
| lysstyrke | 800 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) |
| vise farver | 16.7M (8-bit), CIE193170% |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 9S4PWLEDWithout Driver |
| signal interface | LVDS (2 ch, 8-bit), 41 pins |
| indgangsspænding | 3.3/6.27/-12/18V (Typ.)(VCC/AVDD/VGH/VGL) |
| Ansøgning | CNS |
| AT065TN14 | Innolux | 6.5 | 800×480 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| DJ080PA-01C | Innolux | 8.0 | |
| LA080WV1-TD01 | LG Display | 8.0 | 800×480 |
| LB040Q04-TD01 | LG Display | 4.0 | 320×240 |
| PD040QT2 | E Ink | 4.0 | 320×240 |
| PM065WX3 | E Ink | 6.5 | 800×480 |
| PW100XS1 | E Ink | 10.0 | 640×468 |
| TJ123NP01BA | Innolux | 12.3 | 1280×480 |
