| Varenummer | PW100XS1 |
| Mærke | E Ink |
| Størrelse | 10.0 |
| Ansøgning | CNS |
| Løsning | 640×468 |
| Sammensætning | LCM |
| Lysstyrke | 350 |
| CR | 350:1 |
| Farver | Full color |
| Baggrundsbelysning | CCFL |
| Interface | Analog |
| panel mærke | PVI |
| panel model | PW100XS1 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 10.0 inch |
| løsning | 640(RGB)×468 |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 216×129.636 mm |
| omrids | 235×145.8×6.4 mm |
| overflade | Antiglare |
| lysstyrke | 350 cd/m² (Typ.) |
| kontrastforhold | 350:1 (Typ.) |
| vise farver | Full color |
| responstid | 15/25 (Typ.)(Tr/Td) |
| synsvinkel | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | TFT Specific Analog RGB, 32 pins |
| indgangsspænding | 3.3/3.3/13.0/20.0/-8.0V (VCC/VDD1/VDD2/VGH/VEE) |
| Ansøgning | CNS |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| C065GW02 V1 | AUO | 6.5 | 400×234 |
| C080VW04 V0 | AUO | 8.0 | 800×480 |
| CLAA070LC05CW | CPT | 7.0 | 800×480 |
| CLAA088WA01XN | CPT | 8.8 | 1280×480 |
| L5F30947T0A | Epson | 6.5 | 800×480 |
| LQ050T5DG01 | SHARP | 5.0 | 400×240 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| LTA065B626A | TOSHIBA | 6.5 | 400×234 |
| PA080XS2 | E Ink | 7.9 | 480×468 |
