| Varenummer | AX080E002B |
| Mærke | KOE |
| Størrelse | 31.5 |
| Ansøgning | LCTV |
| Løsning | 1366×768 |
| Sammensætning | LCM |
| Lysstyrke | 500 |
| CR | 950:1 |
| Farver | 16.7M |
| Baggrundsbelysning | EEFL |
| Interface | LVDS |
| panel mærke | IPS Alpha |
| panel model | AX080E002B |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 31.5 inch |
| løsning | 1366(RGB)×768 , WXGA |
| visningstilstand | IPS-Pro, Normally Black, Transmissive |
| aktivt område | 697.685×392.256 mm |
| omrids | 760×450 mm |
| overflade | Antiglare |
| lysstyrke | 500 cd/m² (Typ.) |
| kontrastforhold | 950:1 (Typ.) |
| vise farver | 16.7M (8-bit) |
| responstid | 8/6 (Typ.)(Tr/Td); 17 (Typ.)(MPRT) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 16 pcsEEFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 8-bit), 41 pins |
| indgangsspænding | 12.0V (Typ.) |
| Ansøgning | LCTV |
| AX080A080G | KOE | 31.5 | 1366×768 |
| AX080D002F | KOE | 31.5 | 1366×768 |
| AX080E002B | KOE | 31.5 | 1366×768 |
| HV320WX2-500 | BOE | 31.5 | 1366×768 |
| LC320EXJ-SEE2 | LG Display | 31.5 | 1366×768 |
| LC320EXN-SEA3 | LG Display | 31.5 | 1366×768 |
| LC320WUD-SBM2 | LG Display | 31.5 | 1920×1080 |
| LTA320AP32 | Samsung | 31.5 | 1366×768 |
| T320XVN01.0 | AUO | 31.5 | 1366×768 |
| V315B6-L02 | Innolux | 31.5 | 1366×768 |
| LC420EQE-PGM1 | LG Display | 42 | 3840×2160 |
| LC420EUE-SEM4 | LG Display | 42 | 1920×1080 |
| LC420WUN-SAA1 | LG Display | 42 | 1920×1080 |
| LC550EUH-RDA2 | LG Display | 55 | 1920×1080 |
| LTY460HB01 | Samsung | 46 | 1920×1080 |
| T230XW01 V1 | AUO | 23.0 | 1366×768 |
| T315HW07 V0 | AUO | 31.5 | 1920×1080 |
| T420HVN01.1 CELL | AUO | 42 | 1920×1080 |
| T420HVN02.0 | AUO | 42 | 1920×1080 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
