| Varenummer | B080XAN02.0 |
| Mærke | AUO |
| Størrelse | 7.9 |
| Ansøgning | PAD |
| Løsning | 768×1024 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 600:1 |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | MIPI |
| panel mærke | AUO |
| panel model | B080XAN02.0 1 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 7.9 inch |
| løsning | 768(RGB)×1024 , XGA |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 119.808×159.744 mm |
| omrids | 130.7×173.19×4.35 mm |
| overflade | Hard coating |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 600:1 (Typ.) |
| vise farver | 262K (6-bit), CIE193150% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 4S5PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 35 pins |
| indgangsspænding | 3.7V (Typ.) |
| Ansøgning | PAD |
