| Varenummer | B131HW02 V0 |
| Mærke | AUO |
| Størrelse | 13.1 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 500:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B131HW02 V0 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 13.1 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 289.152×162.648 mm |
| omrids | 299.1×184.3×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (4H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 500:1 (Typ.) |
| vise farver | 16.7M (8-bit), Adobe96% |
| responstid | 3/13 (Typ.)(Tr/Td) |
| synsvinkel | 55/55/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 6 stringsWLEDWithout Driver |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 2.5V (Typ.) |
| Ansøgning | NBPC |
| B131HW02 V0 | AUO | 13.1 | 1920×1080 |
| B131RW02 V0 | AUO | 13.1 | 1600×900 |
| LT131DEVHV00 | TOSHIBA | 13.1 | 1366×768 |
| LTD131EQ2X | TOSHIBA | 13.1 | 1600×900 |
| LTD131EWSX | TOSHIBA | 13.1 | 1366×768 |
| B101EW01 V0 | AUO | 10.1 | 1280×720 |
| B133EW07 V2 | AUO | 13.3 | 1280×800 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B141EW02 V3 | AUO | 14.1 | 1280×800 |
| B141PW03 V1 | AUO | 14.1 | 1440×900 |
| LP154WP3-TLA3 | LG Display | 15.4 | 1440×900 |
| LTN156AT29-L01 | Samsung | 15.6 | 1366×768 |
| M141NWW1-102 | IVO | 14.1 | 1280×800 |
| N156B6-L3D | Innolux | 15.6 | 1366×768 |
| TX31D67VC1CAA | KOE | 12.1 | 1024×768 |
