| Varenummer | B140HAN03.2 HW1A |
| Mærke | AUO |
| Størrelse | 14.0 |
| Ansøgning | Laptop |
| Løsning | 1920×1080 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| fabrikant | AUO |
| modelnavn | B140HAN03.2 HW1A (AUO323D) |
| skærmstørrelse | 14.0 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 157PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 309.37 × 174.02 (H×V) |
| omrids (mm) | 315.1 × 195.65 × 2.4 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Glare (Haze 0%), Hard coating (3H) |
| luminans | 300 cd/m² (Typ.) |
| kontrastforhold | 800 : 1 (Typ.) (TM) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10) |
| respons | 25 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | AHVA, Normally Black, Transmissive |
| farvedybde | 16.2M 72% NTSC |
| baggrundsbelysning | WLED , 15K hours , With LED Driver |
| konturform | Slim (PCBA Flat, T≤3.2mm) |
| anvendes til | Laptop |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | eDP (2 Lanes) , eDP1.3 , HBR1 (2.7G/lane) , Connector 30 pins |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140HAN01.1 | AUO | 14.0 | 1920×1080 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140HAN01.8 | AUO | 14.0 | 1920×1080 |
| B140XW02 V2 | AUO | 14.0 | 1366×768 |
| BT140GW02 V.0 | Innolux | 14.0 | 1366×768 |
| LP140WH1-TLA1 | LG Display | 14.0 | 1366×768 |
| LTN140KT03 | Samsung | 14.0 | 1600×900 |
| M140NWR2 R1 | IVO | 14.0 | 1366×768 |
