| Varenummer | B140HAN01.3 |
| Mærke | AUO |
| Størrelse | 14.0 |
| Ansøgning | NBPC |
| Løsning | 1920×1080 |
| Sammensætning | LCM |
| Lysstyrke | 300 |
| CR | 700:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| panel mærke | AUO |
| panel model | B140HAN01.3 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 14.0 inch |
| løsning | 1920(RGB)×1080 , FHD |
| visningstilstand | AHVA, Normally Black, Transmissive |
| aktivt område | 309.14×173.89 mm |
| omrids | 320.4×205.6×3 mm |
| form stil | Slim (PCBA Flat, Depth ≤3.2mm) |
| overflade | Antiglare, Hard coating (3H) |
| lysstyrke | 300 cd/m² (Typ.) |
| kontrastforhold | 700:1 (Typ.) |
| vise farver | 16.2M (6-bit + FRC), CIE193172% |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | WLEDEmbedded (LED Driver) |
| signal interface | eDP (2 Lanes), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140HAN01.1 | AUO | 14.0 | 1920×1080 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140HAN01.8 | AUO | 14.0 | 1920×1080 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| HB140WX1-501 | BOE | 14.0 | 1366×768 |
| LTN140AT02-B01 | Samsung | 14.0 | 1366×768 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| LP140WH2-TLM1 | LG Display | 14.0 | 1366×768 |
| LP154WX7-TLB1 | LG Display | 15.4 | 1280×800 |
| LTD133EWDD | TOSHIBA | 13.3 | 1280×800 |
| LTM11C307S | TOSHIBA | 11.3 | 1024×768 |
| LTN133AT17-H01 | Samsung | 13.3 | 1366×768 |
| LTN156AT17-103 | Samsung | 15.6 | 1366×768 |
| LTN170WU-L01 | Samsung | 17.0 | 1920×1200 |
| LTN184KT01-J01 | Samsung | 18.4 | 1680×945 |
| N140FGE-L31 | Innolux | 14.0 | 1600×900 |
