| Varenummer | B154EW02 V0 |
| Mærke | AUO |
| Størrelse | 15.4 |
| Ansøgning | NBPC |
| Løsning | 1280×800 |
| Sammensætning | LCM |
| Lysstyrke | 200 |
| CR | 400:1 |
| Farver | 262K |
| Baggrundsbelysning | CCFL |
| Interface | LVDS |
| panel mærke | AUO |
| panel model | B154EW02 V0 2 Compatible model |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 15.4 inch |
| løsning | 1280(RGB)×800 , WXGA |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 331.2×207 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| lysstyrke | 200 cd/m² (Typ.) |
| kontrastforhold | 400:1 (Typ.) |
| vise farver | 262K (6-bit) |
| responstid | 4/12 (Typ.)(Tr/Td) |
| synsvinkel | 45/45/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvens | 60Hz |
| lampe type | 1 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 6-bit), 30 pins |
| indgangsspænding | 3.3V (Typ.) |
| Ansøgning | NBPC |
| B154EW01 V3 | AUO | 15.4 | 1280×800 |
| B154EW01 V8 | AUO | 15.4 | 1280×800 |
| B154EW01 V9 | AUO | 15.4 | 1280×800 |
| B154EW01 VC | AUO | 15.4 | 1280×800 |
| B154EW02 V1 | AUO | 15.4 | 1280×800 |
| B154EW02 V6 | AUO | 15.4 | 1280×800 |
| B154EW02 V7 | AUO | 15.4 | 1280×800 |
| B154EW03 V1 | AUO | 15.4 | 1280×800 |
| B154EW08 V1 | AUO | 15.4 | 1280×800 |
| B154EW09 V2 | AUO | 15.4 | 1280×800 |
| B133HAN02.5 | AUO | 13.3 | 1920×1080 |
| HB125WX1-100 | BOE | 12.5 | 1366×768 |
| LP133WH2-TLM4 | LG Display | 13.3 | 1366×768 |
| LP154WU1-TLB1 | LG Display | 15.4 | 1920×1200 |
| LP156WF3-SLB1 | LG Display | 15.6 | 1920×1080 |
| LTD089EXWS | TOSHIBA | 8.9 | 1280×768 |
| LTN133AT23-B01 | Samsung | 13.3 | 1366×768 |
| LTN150PG-L03 | Samsung | 15.0 | 1400×1050 |
| N140FGE-E32 | Innolux | 14.0 | 1600×900 |
| N140O6-L02 | Innolux | 14.0 | 1600×900 |
