| Varenummer | B173HAN03.0 |
| Mærke | AUO |
| Størrelse | 17.3 |
| Ansøgning | Laptop Gaming |
| Løsning | 1920×1080 |
| Sammensætning | LCM , a-Si TFT-LCD |
| Lysstyrke | |
| CR | 800:1 |
| Farver | 16.2M |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| fabrikant | AUO |
| modelnavn | B173HAN03.0 (AUO309D) |
| skærmstørrelse | 17.3 inch |
| skærmtype | LCM , a-Si TFT-LCD |
| pixel antal | 1920(RGB)×1080 (FHD) 127PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 381.888 × 214.812 (H×V) |
| omrids (mm) | 398.1 × 250.5 × 4 (H×V×D) |
| rammeareal (mm) | - |
| behandling | Antiglare, Hard coating (3H) |
| luminans | 300 cd/m² (Typ.) |
| kontrastforhold | 800 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 9 (Typ.)(Tr+Td) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | AHVA, Normally Black, Transmissive |
| farvedybde | 16.2M 72% NTSC |
| baggrundsbelysning | WLED , 15K hours , With LED Driver |
| konturform | Flat (PCBA Flat, T3.4~4.0mm) |
| anvendes til | Laptop Gaming |
| opdateringshastighed | 144Hz |
| berøringsskærm | Without |
| signaltype | eDP (4 Lanes) , eDP1.4 , HBR2 (5.4G/lane) , 40 pins Connector |
| spændingsforsyning | 3.3V (Typ.) |
| max. vurderinger | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
