| Varenummer | LTN173KT01-W01 |
| Mærke | Samsung |
| Størrelse | 17.3 |
| Ansøgning | NBPC |
| Løsning | 1600×900 |
| Sammensætning | LCM |
| Lysstyrke | |
| CR | |
| Farver | 262K |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| panel mærke | SAMSUNG |
| panel model | LTN173KT01-W01 |
| paneltype | a-Si TFT-LCD , LCM |
| panelstørrelse | 17.3 inch |
| løsning | 1600(RGB)×900 , HD+ |
| visningstilstand | TN, Normally White, Transmissive |
| aktivt område | 382.08×214.92 mm |
| form stil | Wedge (PCBA Bent, Depth ≥5.2mm) |
| overflade | |
| lysstyrke | |
| kontrastforhold | |
| vise farver | 262K (6-bit) |
| responstid | |
| synsvinkel | |
| frekvens | 60Hz |
| lampe type | WLED |
| signal interface | LVDS (2 ch, 6-bit) |
| Ansøgning | NBPC |
| LP173WD1-TLC1 | LG Display | 17.3 | 1600×900 |
| LP173WF1-TLC1 | LG Display | 17.3 | 1920×1080 |
| LTN173KT01-B07 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-D01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-H01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-J01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W01 | Samsung | 17.3 | 1600×900 |
| LTN173KT01-W04 | Samsung | 17.3 | 1600×900 |
| LTN173KT02-W01 | Samsung | 17.3 | 1600×900 |
| LTN173KT03-B01 | Samsung | 17.3 | 1600×900 |
| B141PW03 V0 | AUO | 14.1 | 1440×900 |
| CLAA156WB11A | CPT | 15.6 | 1366×768 |
| LP133WQ1-SJEV | LG Display | 13.3 | 2560×1600 |
| LP133WX3-TLA1 | LG Display | 13.3 | 1280×800 |
| LP140WH2-TPS1 | LG Display | 14.0 | 1366×768 |
| LP154W02-TL10 | LG Display | 15.4 | 1680×1050 |
| LTN160HT01-A02 | Samsung | 16.0 | 1920×1080 |
| LTN184KT01-S02 | Samsung | 18.4 | 1680×945 |
| N116HSE-EA1 | Innolux | 11.6 | 1920×1080 |
| N156BGE-L11 | Innolux | 15.6 | 1366×768 |
