| Varenummer | B173ZAN03.5 |
| Mærke | AUO |
| Størrelse | 17.3 |
| Ansøgning | Laptop Gaming |
| Løsning | 3840×2160 |
| Sammensætning | a-Si TFT-LCD , LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 1.07B |
| Baggrundsbelysning | WLED |
| Interface | eDP |
| mærke | AUO |
| diagonal størrelse | 17.3 inch |
| pixel format | 3840(RGB)×2160 [UHD] 255PPI |
| aktivt område | 381.89(H)×214.81(V) mm |
| luminans | 500 cd/m² (Typ.) |
| visningsretning | Symmetry |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| støtte farve | 1.07B 100% NTSC |
| form stil | Slim (PCBA Flat, T≤3.2mm) |
| billedhastighed | 120Hz |
| interface type | eDP (4 Lanes) , eDP1.4a , 40 pins Connector |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
| model | B173ZAN03.5 (AUO2892) |
| type | a-Si TFT-LCD , LCM |
| konfiguration | RGB Vertical Stripe |
| omrids dim. | 389.89(H)×238.31(V) ×3.5(D) mm |
| kontrastforhold | 1000:1 (Min.) (TM) |
| responstid | 10 (Typ.)(Tr+Td); 8.3 (Typ.)(G to G) |
| driftstilstand | AHVA, Normally Black, Transmissive |
| lyskilde | WLED , 15K hours , With LED Driver |
| designet til | Laptop Gaming |
| berøringspanel | Without |
