| Varenummer | C090EAN04.1 |
| Mærke | AUO |
| Størrelse | 9.0 |
| Ansøgning | Outdoor High Brightn |
| Løsning | 1280×720 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 1000:1 |
| Farver | 16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | AUO |
| model | C090EAN04.1 |
| diagonal størrelse | 9.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×720 [WXGA] 163PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 198.72(H)×111.78(V) mm |
| omrids dim. | 212.2(H)×127.9(V) ×11(D) mm |
| bezel område | 202.02(H)×115.78(V) mm |
| behandling | Antiglare |
| luminans | 900 cd/m² (Typ.) |
| kontrastforhold | 1000:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 30 (Typ.)(Tr+Td) |
| synsvinkel | 80/80/80/80 (Typ.)(CR≥10) |
| driftstilstand | AHVA, Normally Black, Transmissive |
| støtte farve | 16.7M 72% NTSC |
| lyskilde | WLED [8S3P] , 10K hours , W/O Driver |
| vægt | TBD |
| designet til | Outdoor High Brightness Automotive Display |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 8-bit) , 40 pins FPC |
| Strømforsyning | 3.3V (Typ.) |
| miljø | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| A090VW01 V3 | AUO | 9.0 | 800×480 |
| AA090ME01 | Mitsubishi | 9.0 | 800×480 |
| AT090TN23 | Innolux | 9.0 | 1280×800 |
| C090EAN01.1 | AUO | 9.0 | 1280×720 |
| ED090NA-01D | Innolux | 9.0 | 1280×800 |
| ED090NA-01H | Innolux | 9.0 | 1280×800 |
| LTA090A220F | TOSHIBA | 9.0 | 800×480 |
| LTA090B400F | TOSHIBA | 9.0 | 800×480 |
| NL192108AC10-01D | NLT | 9.0 | 1920×1080 |
| TX23D12VM0CAA | KOE | 9.0 | 800×480 |
