| Varenummer | CLAA070LQ02 XN |
| Mærke | CPT |
| Størrelse | 7.0 |
| Ansøgning | Automotive Display |
| Løsning | 800×480 |
| Sammensætning | LCM, a-Si TFT-LCD |
| Lysstyrke | |
| CR | 900:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | 7S2P |
| Interface | LVDS |
| fabrikant | CPT |
| modelnavn | CLAA070LQ02 XN |
| skærmstørrelse | 7.0 inch |
| skærmtype | LCM, a-Si TFT-LCD |
| pixel antal | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| aktivt område (mm) | 152.4 × 91.44 (H×V) |
| omrids (mm) | 165 × 104 × 7.3 (H×V×D) |
| rammeareal (mm) | 154.4 × 93.44 (H×V) |
| behandling | Antiglare (Haze 25%) |
| luminans | 760 cd/m² (Typ.) |
| kontrastforhold | 900 : 1 (Typ.) (TM) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| respons | 25 (Typ.)(Tr+Tf) ms |
| god udsigt kl | Symmetry |
| arbejdstilstand | HFFS, Normally Black, Transmissive |
| farvedybde | 262K/16.7M 70% NTSC |
| baggrundsbelysning | 7S2P WLED , 30K hours , No Driver |
| masse | 175g (Typ.) |
| anvendes til | Automotive Display |
| opdateringshastighed | 60Hz |
| berøringsskærm | Without |
| signaltype | LVDS (1 ch, 6/8-bit) , FPC 60 pins |
| spændingsforsyning | 3.3/13.0/20.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. vurderinger | Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
