| Varenummer | CLAA080WK02 XN |
| Mærke | CPT |
| Størrelse | 8.0 |
| Ansøgning | Automotive Display |
| Løsning | 1280×720 |
| Sammensætning | a-Si TFT-LCD, LCM |
| Lysstyrke | |
| CR | 900:1 |
| Farver | 262K/16.7M |
| Baggrundsbelysning | WLED |
| Interface | LVDS |
| mærke | CPT |
| model | CLAA080WK02 XN |
| diagonal størrelse | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 1280(RGB)×720 [WXGA] 183PPI |
| konfiguration | RGB Vertical Stripe |
| aktivt område | 177.024(H)×99.576(V) mm |
| omrids dim. | 186.5(H)×117.22(V) ×13.1(D) mm |
| bezel område | 179.03(H)×101.58(V) mm |
| behandling | Antiglare (Haze 25%) |
| luminans | 600 cd/m² (Typ.) |
| kontrastforhold | 900:1 (Typ.) (TM) |
| visningsretning | Symmetry |
| responstid | 25 (Typ.)(Tr+Td) |
| synsvinkel | 85/85/85/85 (Typ.)(CR≥10) |
| driftstilstand | HFFS, Normally Black, Transmissive |
| støtte farve | 262K/16.7M 70% NTSC |
| lyskilde | WLED [5S4P] , 30K hours , W/O Driver |
| vægt | TBD |
| designet til | Automotive Display |
| billedhastighed | 60Hz |
| berøringspanel | Without |
| interface type | LVDS (1 ch, 6/8-bit) , 60 pins FPC |
| Strømforsyning | 3.3/12.4/22/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| miljø | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
